3. Electrical installation
3−14
Festo P.BE−CPX−CMA X−SYS−EN en 0908NH
3.4.2 Power supply concept, formation of power zones
The modular power supply concept of the CPX terminal allows
power zones to be formed.
Observe the following:
 The internal electronics of the VPWP and the digital posi
tion measuring system and, if present, the sensor inter
face are supplied with power by the electronics/sensors
operating voltage supply (U
EL/SEN
).
The VPWP load supply and the VPWP outputs are sup
plied with power by the valve load supply (U
VAL
).
 The CMAX internally connects the contact rails 0 V
EL/SEN
to 0 V
VAL
of the CPX terminal.
 This means that the operating power supply for the
electronics/sensors (U
EL/SEN
) of the CPX terminal and
the CMAX load supply for the valves (U
VAL
) are no
longer electrically isolated.
 Complete electrical isolation (all poles) of the valve
supply of the VPWP is therefore not possible, even in
conjunction with a CPX valve supply of type CPX−EV−V.
Note
Damage to components and operative malfunctions!
· The CMAX must be supplied via the same potential
(common power supply unit) as the operating power
supply for the electronics/sensors (U
EL/SEN
) of the
CPX terminal (see also Fig.3/3).
The CMAX always connects the 0 V supply for the elec
tronics with the 0 V supply for the valves. This must be
observed when a CPX−GE−EV−V interlinking block is located
to the left of the CMAX because this can remove any inten
tional electrical
isolation.
