1. CMAX system overview
1−7
Festo P.BE−CPX−CMAX−SYS−EN en 0908NH
1.3 Parameterisation and commissioning options
Tab.1/1 provides an overview of the commissioning,
parameterising and teaching options.
Operated via
Properties For details, see
FCT CMAX plug−in Easy commissioning thanks to special dialogu es
and functions.
Direct on−site" operation with drive monitoring
is possible
PC must be connected on site with the diagnostic
interface of the CPX terminal.
Chapter 4,
help for FCT CMAX
plug−in
Master controller,
CPX node
(CPX bus node or
CPX−FEC)
 Parameteri sati on of several positionin g
systems is possible.
 Commissioning and teachin g require additional
measur es for the necessary drive monitoring.
 Additional programming required.
CMAX communication
profile" description,
P.BE−CPX−CMAX−CON
TROL−...
Tab.1/1: Commissioning, parameterising and teaching options
1.3.1 Festo Configuration Tool (FCT)
The Festo Configuration Tool (abbreviated as FCT) is the soft
ware platform for configuring and commissioning various
Festo components and devices.
The CMAX plug−in for the FCT helps to carry out all the steps
necessary for commissioning a CMAX.
An overview for commissioning with the FCT can be found in
chapter 4.
The help
for the FCT contains the complete information on
operating the Festo Configuration Tool. The device−specific
plug−ins each have their own help files.
