2. Fitting and pneumatic installation
2−17
Festo P.BE−CPX−CMAX−SYS−EN en 0908NH
2.4 VPWP proportional directional control valve
2.4.1 Approved drive/valve combinations
Tab.2/7 contains the approved drive/valve combinations
(as of August 2009).
Use the specified fittings and tubing or appropriate tubes
with the corresponding flow rates.
VPWP sizes 2 and 10 are in preparation.
Depending on the application, you can also use sizes 4 or 8
after consulting with Festo.
Drive
Valve Fitting Tubing
Type Size Length Valve Drive
DGCI 18
100 ... 300 VPWP−2−... QSM−M5−6 QSM−M5−6 PUN−6x1
360 ... 2000 VPWP−4−... QS−1/8−6 QSM−M5−6 PUN−6x1
25
100 ... 160 VPWP−2−... QSM−M5−6 QS−1/8−6 PUN−6x1
225 ... 750 VPWP−4−... QS−1/8−8 QS−1/8−8 PUN−8x1.25
850 ... 2000 VPWP−6−... QS−1/8−8 QS−1/8−8 PUN−8x1.25
32
100 VPWP−2−... QSM−M5−6 QS−1/8−6 PUN−6x1
160 ... 360 VPWP−4−... QS−1/8−8 QS−1/8−8 PUN−8x1.25
450 ... 2000 VPWP−6−... QS−1/8−8 QS−1/8−8 PUN−8x1.25
40
100 ... 300 VPWP−4−... QS−1/8−8 QS−1/4−8 PUN−8x1.25
360 ... 750 VPWP−6−... QS−1/8−8 QS−1/4−8 PUN−8x1.25
850 ... 2000 VPWP−8−... QS−1/4−10 QS−1/4−10 PUN−10x1.5
63
100 ... 160 VPWP−4−... QS−1/8−8 QS−3/8−8 PUN−8x1.25
225 ... 300 VPWP−6−... QS−1/8−8 QS−3/8−8 PUN−8x1.25
360 ... 450 VPWP−8−... QS−1/4−10 QS−3/8−10 PUN−10x1.5
500 ... 2000 VPWP−10−... QS−3/8−12 QS−3/8−12 PUN−12x2
