2. Fitting and pneumatic installation
2−18
Festo P.BE−CPX−CMA X−SYS−EN en 0908NH
Drive TubingFittingValve
Type
Tubing
DriveValve
Valve
LengthSize
DGP(I)(L) 25
225 ... 750 VPWP−4−... QS−1/8−8 QS−1/8−8 PUN−8x1.25
1000 ... 2000 VPWP−6−... QS−1/8−8 QS−1/8−8 PUN−8x1.25
32
225 ... 300 VPWP−4−... QS−1/8−8 QS−1/8−8 PUN−8x1.25
360 ... 2000 VPWP−6−... QS−1/8−8 QS−1/8−8 PUN−8x1.25
40
225 VPWP−4−... QS−1/8−8 QS−1/4−8 PUN−8x1.25
300 ... 750 VPWP−6−... QS−1/8−8 QS−1/4−8 PUN−8x1.25
1000 ... 2000 VPWP−8−... QS−1/4−10 QS−1/4−10 PUN−10x1.5
50
225 ... 500 VPWP−6−... QS−1/8−8 QS−1/4−8 PUN−8x1.25
600 ... 2000 VPWP−8−... QS−1/4−10 QS−1/4−10 PUN−10x1.5
63
225 ... 1000 VPWP−8−... QS−1/4−10 QS−3/8−10 PUN−10x1.5
1250 ... 2000 VPWP−10−... QS−3/8−12 QS−3/8−12 PUN−12x2
DNCI,
DNC
32
50 ... 150 VPWP−2−... QSM−M5−6 QS−1/8−6 PUN−6x1
DNC,
DNCM
150 ... 400 VPWP−4−... QS−1/8−8 QS−1/8−8 PUN−8x1.25
DNCM
> 400 VPWP−6−... QS−1/8−8 QS−1/8−8 PUN−8x1.25
40
50 ... 300 VPWP−4−... QS−1/8−8 QS−1/4−8 PUN−8x1.25
> 300 VPWP−6−... QS−1/8−8 QS−1/4−8 PUN−8x1.25
50
50 ... 200 VPWP−4−... QS−1/8−8 QS−1/4−8 PUN−8x1.25
200 ... 900 VPWP−6−... QS−1/8−8 QS−1/4−8 PUN−8x1.25
> 900 VPWP−8−... QS−1/4−10 QS−1/4−10 PUN−10x1.5
63
50 ... 300 VPWP−6−... QS−1/8−8 QS−3/8−8 PUN−8x1.25
300 ... 1000 VPWP−8−... QS−1/4−10 QS−3/8−10 PUN−10x1.5
> 1000 VPWP−10−... QS−1/4−10 QS−3/8−10 PUN−10x1.5
DSMI
25  (270°) VPWP−2−... QSM−M5−6 QSM−M5−6 PUN−6x1
40  (270°) VPWP−4−... QS−1/8−8 QS−1/8−8 PUN−8x1.25
Tab.2/7: Drive/valve combinations
