4. Commissioning
4−17
Festo P.BE−CPX−CMAX−SYS−EN en 0908NH
4.5.1 Defining the operating mode with CCON
Operating mode Description
Record select operating mode
 Record select mode
(OPM1 = 0; OPM2 = 0)
The PLC selects a record from a record list stored in the CMAX.
A record contains all the parameters which are specified for a posi
tioning job. The record number is transferred to the cyclical I/O data
as the setpoint or actual value.
Direct operating mode
 Direct mode
(OPM1 = 1; OPM2 = 0)
The positioning job is transferred directly into the cyclical I/O data.
The most important setpoint values (position, speed, force) are
transferred here. Supplementary parameters (e.g. acceleration) are
defined via parameterisation.
Commissioning operating
mode
(OPM1 = 0; OPM2 = 1)
Commissioning functions (e.g. identification) can be executed and
parameters read or written. Positioning jobs are not possible.
Parametrising operating
mode
(OPM1 = 1; OPM2 = 1)
A parameter is transferred into the I/O data according to the FPC
protocol. Positioning jobs are not possible.
Tab.4/2: Overview of CMAX operating modes
CCON All the statuses which must be available in all operating
modes are controlled with control byte 1 (CCON).
Allocation of the control byte CCON (byte 1)
CCON
B7
OPM2
B6
OPM1
B5
LOCK
B4

B3
RESET
B2
BRAKE
B1
STOP
B0
ENABLE
Operating mode
selection
Software
access
blocked
 Acknow−
ledge
malfunc
tion
Release
brake
Stop Enable
drive
SCON Status byte 1 (SCON) signals the status of the CMAX in all
operating modes.
Allocation of the status byte SCON (byte 1)
SCON
B7
OPM2
B6
OPM1
B5
FCT_MMI
B4
24VL
B3
FAULT
B2
WARN
B1
OPEN
B0
ENABLED
Acknowledgement of
operating mode
Device
control
software
Load
voltage
applied
Malfunc
tion
Warning Oper
ation
enabled
Drive en
abled
