2. Fitting and pneumatic installation
2−8
Festo P.BE−CPX−CMA X−SYS−EN en 0908N H
Note
Please observe the notes in the operating instructions for
the drive used. Make sure that the following are complied
with:
the permitted lateral force
the p
ermitted longitudinal force
the permitted mass moment of inertia
the maximum permitted speeds and swivel frequencies.
2.3.2 Drive, shock absorbers and fixed stops
Drive
Note
With all work, be sure to follow the mounting instructions
in the operating instructions.
Use only the permitted drives with suitable guide listed in
Tab.2/1
(as of August 2009).
Consult Festo if you wish to use other drives.
Drive
Notes
DGP(L) · Completely unscrew the adjusting screws for the end−position cushioning (PPV) on
both sides.
DNC Note
The following DNC variants are not permitted for use with the CMAX:
Slow speed variant S10
Low friction variant S11
Temperature−resistant variant S6 (only on request).
Use only:
DNC variants with permitted maximum piston speed Vmax > 1 m/s.
For standard cylinders with end−position cushioning PPV:
· Completely unscrew the adjusting screws for the end−position cushioning (PPV) on
both sides.
Tab.2/2: Instructions for the drives DGP(L) and DNC
