2. Fitting and pneumatic installation
2−6
Festo P.BE−CPX−CMA X−SYS−EN en 0908N H
2.3 Installation of the drive and position measuring system
Use only the drive/displacement encoder combinations
approved by Festo for the CMAX.
Note
In order to avoid damage due to uncushioned movement
into the end positions:
· Use appropriate shock absorbers.
· Define the software end positions.
To avoid damage to the displacement encoder when the
displacement encoder is shorter than the drive stroke:
· Limit the travel range with additional end stops.
Tab.2/1 shows the approved drive/displacement encoder
combinations:
Drive
Displacement encoder Sensor
Design Type Design, function Type
interface
Linear drive
DGCI Digital (absolute) Integrated
DGP(L) Potentiometer (absolute) MLO−POT−TLF−... CA SM−S−D2−R3
Cylinder
DNCI Encoder (incremental) Integrated CASM−S−D3−R7
DNC Potentiometer (absolute) MLO−POT−LWG−... CASM−S−D2−R3
DNCM Potentiometer (absolute) Integrated CASM−S−D2−R3
Semi−rotary drive DSMI Potentiometer (absolute) Integrated CASM−S−D2−R3
Tab.2/1:Drive overview (as of August 2009)
Further drives are in preparation.
