2. Fitting and pneumatic installation
2−24
Festo P.BE−CPX−CMA X−SYS−EN en 0908NH
2.6.2 Filter regulator
· Use a filter regulator consisting of a compressed air filter
and a regulating valve (e.g. LFR−...−D−... with 5ìm filter
cartridge ) in conjunction with a soft− start valve (e.g. HEL):
without lubrica t o r
with a 5 m filter
with sufficiently large sta nda rd nominal flow rate
corre s po n di n g to the air requirement of the connected
drive during
positi oning. Reference value: twice the stan
dard nominal flow rate of the valve (type VPWP), e.g.:
Valve (fitting)
Filter regulator
VPWP−2−... (M5) LFR−1/8−D−5M−MINI or
MS4−LFR−1/4−D7−CRM−AS
VPWP−4−... (1/8) LFR−1/8−D−5M−MINI or
MS4−LFR−1/4−D7−CRM−AS
VPWP−6−... (1/8) LFR−1/4−D−5M−MINI or
MS4−LFR−1/4−D7−CRM−AS
VPWP−8−... (1/4) LFR−3/8−D−5M−MIDI or
MS6−LFR−1/4−D7−CRM−AS
VPWP−10−... (3/8) LFR−3/4−D−5M−MAXI or
MS6−LFR−3/8−D7−CRM−AS
Tab.2/9: Selection of filter regulator
· Use a fine filter or micro filter if you cannot avoid slight oil
mist from the compressed air supply.
