3. Electrical installation
3−8
Festo P.BE−CPX−CMA X−SYS−EN en 0908NH
Technical data Value
Digital output (pin 2)
 Activation
 Supply
 Max. current
 Fuse protection
 Version
 Galvanic isolation
Via I/O data
from 24 V
VAL
500 mA
protected against short circuits
1)
in acc. with IEC 61131−2, positive logic (PNP)
no
Voltage output
(load voltage, pin 4)
 Supply
 Max. current
 Fuse protection
from 24 V
VAL
500 mA
protected against short circuits
1)
1)
Temperature switch−off: Maximum short−circuit current (short
term) is defined only by the cable and connection resistances
Tab.3/5: Technical data of connection DO
