Festo CPX-CMAX-C1-1 Mounting, Installation And Diagnostics

Contents and general safety instructions
XV
Festo P.BE−CPX−CMAX−SYS−EN en 0908NH
This description contains information on the following
modules and components of the positioning system:
Module/component type
Description
CMAX−C1−1 CMAX axis controller with 7−segment display as well as an axis
interface to the VPWP.
The CMAX is a CPX module (technolog y module) in a CPX termi nal .
VPWP −... VPW P proportional directional control valve with connections to the
CMAX and to the displacement encoder or sensor interface.
The position measuri n g system or sensor interface is connected to
the VPWP.
Additional digital output with a load voltage supply for activating a
brake or clamping unit.
CASM−S−D2−R3
CASM−S−D3−R7
Sensor interfaces with a connection to the VPWP, for connecting
special position measurin g systems to the axis string:
analogue, absolute displacement en coders (potentiometer s)
 digital, incremental displacement encoders
DGCI−...
DGP(L)−... with
MLO−POT−...−T LF
DNCI−...
DNC−... with
MLO−POT−...−LWG
DNCM−...
DSMI−...
Enabled drives with position measurin g systems:
1)
 Lin ear drive with permanen tly integrated position measurin g
system.
(digital, absol ute)
 Lin ear drive with extern al position measuring system
(potenti ometer, absol ute)
Standard cylinder with integrated position measurin g system
(en cod er, incremen tal )
Standard cylinder with external position measuri ng system
(potenti ometer, absol ute)
Standard cylinder with external position measuri ng system
(potenti ometer, absol ute)
 Semi−rotary drive with integrated position measurin g system
(potenti ometer, absol ute)
1)
Support for other drives in preparation
Tab.0/2: Over view of positioning system modules and components

Festo CPX-CMAX-C1-1 Specifications

General

Brand	Festo
Model	CPX-CMAX-C1-1
Category	Controller
Language	English
