2. Fitting and pneumatic installation
2−20
Festo P.BE−CPX−CMA X−SYS−EN en 0908NH
H−rail mounting
You will require the following mounting kit to mount the
VPWP on H−rails.
Valve
Mounting
P. No. Type
VPWP−2, ...−4, ...−6 527392 CPASC1−BG−NRH
VPWP−8, ...−10 123491 CPV10−VI−BG−NRH
Tab.2/8: VPWP H−rail mounting set
Mounting onto an H−rail:
1. Ensure that the mounting surface can carry the weight of
the VPWP.
2. Mount the H−rail (DIN mounting rail EN 60715−TH35).
Be sure to leave sufficient space for connecting the
supply cables and tubes.
3. Screw the 2 clips from the mounting kit to the VPWP using
the
screws provided (see Fig.2/6).
Tightening torque: 1.5 Nm.
Make sure that the fixing bolts of the clip engage in the
recess of the VPWP.
4. Hang the VPWP on the H−rail. Secure against tipping or
slipping on both sides by using the H−rail clamping.
