3. Electrical installation
3−6
Festo P.BE−CPX−CMA X−SYS−EN en 0908NH
Connecting cables for the axis string Length Type
Connecting cable WS−WD
angled plug/angled socket
0.25 m KVI−CP−3−WS−WD−0.25
angled plug/angled socket
0.5 m KVI−CP−3−WS−WD−0.5
2 m KVI−CP−3−WS−WD−2
5 m KVI−CP−3−WS−WD−5
8 m KVI−CP−3−WS−WD−8
Connecting cable GS−GD
straight plug/straight socket
2 m KVI−CP−3−GS−GD−2
straight plug/straight socket
5 m KVI−CP−3−GS−GD−5
8 m KVI−CP−3−GS−GD−8
Connecting piece
for control cabinet feedthrough
KVI−CP−3−SSD
Tab.3/3: Over view of cables between CMAX, VPWP, sensor interface, displacement
encoder
