Fidelity Electronics A10 - Parameters Table for Pc;Command;Serial Scanner; Parameters Table for Auto 1 ~ 3 & Manual

27
• Auto 2 = The highest stable weight value (of a weighing process) will be printed when all loads are
removed (and the gross weight returns to zero or minus).
• Auto 3 = The last stable weight value (of a weighing process) will be printed when all loads are
removed (and the gross weight returns to zero or minus).
• Manual = Manual output by pressing [Print/M+].
• PC = Continuous or selected periodic output of real-time result according to the predefined format.
• CMD = Command communication with computer and APP mode.
• Scaner = Barcode Scanner.
Notes: -
• If PC/CMD/Scaner is set, refer to paragraph 8.2 for the rest of the setting.
• If Auto 1 ~ 3 or Manual is set, refer to paragraph 8.3 for the rest setting.
5. Repeat the above steps 1 ~ 4 for all other UARTs.
8.2 Parameters Table for PC/Command/serial Scanner
Step
No.
Set Item
Parameters
PC
CMD
Scanner
1
Baud Rate
1200 ~ 921600 in 12 steps
Default = 115200
■
■
■
2
Parity
None/Odd/Even
Default = None
■
■
■
3
Data Length
7/8
Default = 8
■
■
■
4
Protocol Type
(Note G)
Protocol 0 ~ 9 & Custom
Default = Protocol 1
■
Completed
Completed
5
Transmission
Interval (Note
A)
0 ~ 300 (second) in 10 steps
Default = 0
Completed
8.3 Parameters Table for Auto 1 ~ 3 & Manual
Step
No.
Set Item
Parameters
Auto 1
Auto 2
Auto 3
Manual
1
Baud Rate
1200 ~ 921600 in 12 steps
Default = 115200
■
■
■
■
2
Parity
None/Odd/Even
Default = None
■
■
■
■
3
Data Length
7/8
Default = 8
■
■
■
■
4
Auto
Accumulation
(Note B)
Off/On
Default = On
■
■
■
■
5
Check Control
(Note C)
Off/On
Default = Off
■
■
■
■
6
Stability Control
(Note D)
Yes/No
Default = Yes
■
■
■
■
7
Minimum Output
Weight (Note E)
10 ~ 20d in 11 steps
Default = 20d
■
■
■
■
8
Output Format
(Note F)
Lab 1 ~ Lab 5, LP 50, TSC and
Sbarco
■
■
■
■
