Appendix C: - Lab 1 Output Formats
No header generated when line number is set = 00. See below tables for print format illustrations and explanations.
C.1 Weighing, ATM & Animal Mode Illustration
Date
Time
Seq
Mode
Net
Tare
Gross
Total
Result
2021-03-28
20:36:28
1
W
1.500kg
0.000kg
1.500kg
1.500kg
Accept
2021-03-28
20:36:30
2
W
1.500kg
0.000kg
1.500kg
3.000kg
Accept
2021-03-28
20:36:31
3
W
1.500kg
0.000kg
1.500kg
4.500kg
Accept
2021-03-28
20:36:33
4
W
3.000kg
0.000kg
3.000kg
7.500kg
Above
C.2 Piece Count Mode Illustration
Date
Time
Seq
Mode
Net
Tare
Gross
Total_WT
QTY
@WT
Total_QTY
Result
2021-03-28
11:43:00
1
C
5.000kg
0.000kg
5.000kg
5.000kg
10
499.968 g
10pcs
Below
2021-03-28
11:43:02
2
C
10.000kg
0.000kg
10.000kg
15.000kg
20
499.968 g
30pcs
Below
2021-03-28
11:43:05
3
C
15.000kg
0.000kg
15.000kg
30.000kg
30
499.968 g
60pcs
Accept
2021-03-28
11:43:08
4
C
19.996kg
0.000kg
19.996kg
49.996kg
40
499.968 g
100pcs
Accept
Explanations: -
• Date = Date of Output
• Time = Time of Output
• Seq = Accumulate Sequence No
• M = Working Mode
o W = Weighing, C = Piece count, P = Percentage
• Net = Net Weight
• Tare = Tare Weight
• Gross = Gross Weight
• Total_WT = Total Accumulated Weight
• @WT = Average piece weight
• Total_QTY = Total Accumulated Quantity
• Result = Check Result: -
o Accept = Within Lo & Hi limit
o Below = Lower than Lo limit
o Above = Higher than Hi Limit
