Appendix N: - Management Report Execution Commands
Management report execution command format as below: -
d. Start String * “asterisk” (Hex code 02A), followed by
e. Command code as shown on below table (all commands are case sensitive), followed by
f. End String # “number sign” (Hex code 23).
Notes: -
 For RS485 communication, add @xx before start string.
 xx = machine ID number set in F18.
Command Definition
Command Format
Parameter Description
Start
String
Command
Code
Parameter &
End String
Output all data in Alibi memory.
*
EX
RPTA
;d1;d2;d3;d4#
Search Criteria
 d1 = Operator number 0000~9999. Blank = all.
 d2 = C Code. 1~18 digit Customer Code. Blank = all.
 d3 = P Code. 1~18 digit Product Code. Blank = all.
 d4 = Check Result. Lo = Below; OK = Accept; Hi = Above;
NG = Lo or HI. Blank = all.
Output data of today in Alibi
memory.
*
EX
RPTD
;d1;d2;d3;d4#
Output data of current month in
Alibi memory.
*
EX
RPTM
;d1;d2;d3;d4#
Output data of specific period in
Alibi memory.
*
EX
RPTP
;d1;d2;d3;d4;d5;d
6#
Search Criteria
 d1 = Data starting date. 6 digit according F4 setting.
 d2 = Data ending date. 6 digit according F4 setting
 d3 = Operator number 0000~9999. Blank = all.
 d4 = C Code. 1~18 digit Customer Code. Blank = all.
 d5 = P Code. 1~18 digit Product Code. Blank = all.
 d6 = Check Result. Lo = Below; OK = Accept; Hi = Above;
NG = Lo or HI. Blank = all.
