B.2 Customized PC Output Content Table
Symbol
Explanations
Nature
No. of Digit
Remarks
CoMMA
Comma
Data Separator
1
Select either one
SemiCo
Semicolon
1
Cr LF
HEX Code 0D 0A
Control Code
2
Cr
HEX code 0D
1
LF
HEX code 0A
1
SOH
HEX code 01
1
STX
Hex code 02
1
ETX
Hex code 03
1
Status
Weigh Status
Transaction Data
2
 ST = Stable
 US = Unstable
 OL = Overload
nT-GS
Net/Gross Sign
2
NT = Net/GS = Gross
Date
Date of Output
10
Time
Time of Output
8
Net
Net Weight
8
Numeric value only,
without weight unit
Tare
Tare Weight
8
Gross
Gross Weight
8
Unit
Weight Unit
2
 kg = Kilogram
 (space)g =gram
H ref
Hi Limit
8
8-digital including decimal (if any)
L ref
Lo Limit
8
8-digital including decimal (if any)
Ck res
Comparison Result
2
Lo/Ok/Hi/Grade Result for grading
id
Machine ID
2
00 ~ 98, Blank = None
Group
Machine Group Number
2
00 ~ 99, Blank = None
Op Code
Operator Number
4
0000 ~ 9999, Blank = None
