Appendix P1: - System Parameter & Operation Entry Reading Commands
Operation entry reading command format as below: -
a. Start String * “asterisk” (Hex code 02A), followed by
b. Command code as shown on below table (all commands are case sensitive), followed by
c. End String # “number sign” (Hex code 23).
Notes: -
 For RS485 communication, add @xx before start string.
 xx = machine ID number set in F18.
Command Description Table
Command Definition
Command Format
Parameter
Output
Parameter Description
Start
String
Command Code
End
String
Read Internal AD value
*
RD
F001
#
d1
8 digit AD value
Read Capacity, Division &
Default Weight Unit
*
RD
F003
#
d1;d2
d1 = Capacity x Division of W1
d2 = Capacity x Division of W2 (if set)
Read Date Format, Value
and Output Settings
*
RD
F004
#
d1:d2;d3
d1 = Date Format (0 = DD-MM-YY, 1 = YY-MM-DD, 3 =
MM-DD-YY)
d2 = 8-digit date value as per above setting (AA-BB-CC)
d3 = Date Output Format (0 = Normal Format, 1 = Week
Format)
Read Time
*
RD
F005
#
d1
8-digit time value (HH:MM:SS)
Read Auto Power Off
*
RD
F007
#
d1
0 = Off
1 = 1 minute
2 = 3 minute
3 = 5 minute
4 = 10 minute
5 = 20 minute
