Appendix U: Production Settings PLU Reading Commands
Production Settings PLU reading commands format as below: -
a. Start String * “asterisk” (Hex code 02A), then followed by
b. Command string listed on below table, then followed by
c. Parameters listed on the below table. Always insert semicolon (;) in front of each parameter, followed by
d. End String # “number sign” (Hex code 23).
Notes: -
 For RS485 communication, add @xx before start string.
 xx = machine ID number set in F18.
U.1 Command Description Table
Start
String
Command Code
(Note U1)
Parameter &
End String
Parameter Output
*
R1 or R2 or R3
LP
;01~;99 or ;A
(01~99 = PLU number. A = all)
d1;d2;d3… ;d14
Remark: If parameter A is inputted, instrument sends content of quick from PLU 01 to PLU 99 in numeric sequent.
Note U1: -
• R1 = command to read content from Production Settings PLU of weight unit kg.
• R2 = command to read content from Production Settings PLU of weight unit g.
• R3 = command to read content from Production Settings PLU of weight unit lb.
Refer to below table for content of output. A semicolon is inserted between parameters.
U.2 Parameter Output Description Table
Parameter #
Parameter Output
Parameter Description
d1
Weight Unit Code
U1 = kg
U2 = g
U3 = lb
d2
PLU #
01 ~ 99
