Fidelity Electronics A10 - 6.4 Internal Function Table

16
6.4 Internal Function Table
No.
Description
Parameters/Note
Default = **
F1
Analogue to Digital
(AD) Value
Press [Print/M+] or [Tare] to set the offset value to zero when unloaded. Then add load to observe the span value of
load applied.
 When ADC is more than 1 million. W
1
sign appears. Actual ADC is = 1 million + the ADC value being
displayed.
 When ADC is more than 2 million. W
2
sign appears. Actual ADC is = 2 million + the ADC value being
displayed.
 When ADC is more than 3 million. Both W
1
& W
2
sign appear. Actual ADC is = 3 million + the ADC value
being displayed.
Press [Zero] to quit to F1.
F2
All Segment Check
Lit up all display segments, indication, and backlight colors. Check for missing segments and backlight brightness & color
ratio.
Press [Zero] to quit to F2 or [Check] to show current battery voltage.
F3
Capacity, Division &
Default Weight Unit
Display basic metrology characteristics (capacity, division, and weight unit). The value displayed in the format of: -
• Max + 1e for single interval mode.
• Max
1
+ e
1
and Max
2
+ e
2
for dual weighing range/interval mode.
Press [Zero] to quit to F3.
F4
Date Format & Value
DD/MM/YY
** YY/MM/DD
MM/DD/YY
• Press [Unit] or [MR] to change date format and press [Print/M+] to confirm.
• Press [Print/M+] to check the current date value.
• To adjust date value, input date value and press [Print/M+] to confirm.
• Instrument will then display the date value inputted into week and day number (0 ~ 6 for Sunday ~ Saturday) of the year value inputted.
• Select Date Output Type: - 2 parameters are available: -
➢ Date = Normal date format as per input above.
➢ Week = WWYYDD format. WW = week number; YY = year value; DD = weekday (Monday = 01… Sunday = 07).
F5
Time
HH:MM:SS in 24-hour format
