Note A: - Transmission interval is the time interval (in second) between each output. 0 = continuous output.
Note B: - On = Auto Memory accumulation enabled.
Off = Auto Memory accumulation disabled.
Note C: - On = (When check function is in effect) Only OK value (value which is within Lo and Hi Limits) will
be processed.
Off = (When check function is in effect) Check control is disabled.
Note D: - Yes = Only stable weight will be processed.
No = Transmission is activated when [Print/M+] is pressed disregarding the weight stable status.
Note E: - Minimum weight value to be transmitted. No data will be processed if the weight detected is less
than the minimum output weight selected here.
Note F: - Output format description: -
• Lab 1 = Output in landscape direction. Refer to Appendix C for more information.
• Lab 2 = Output in portrait direction. Refer to Appendix D & E for more information.
• Lab 3 = Database output mode. Refer to Appendix F for more information.
• Lab 4 = Journal output format with the gross and net weight of each transaction. Refer to
Appendix G for more information.
• Lab 5 = Journal output format with time and net weight of each transaction. Refer to Appendix
H for more information.
• LP-50 = Output to LP-50 label printer. Refer to Appendix K for more information.
• LP-50/TSC/Sbarco = Output to LP-50/TSC/Sbarco label printer. Refer to Appendix I ~ K for
more information.
Note G: -
• Refer to Appendix A for Predefined PC Output Prot 0 ~ Prot 9.
• Refer to Appendix B for Customized PC Output Protocol.
Note H: - If Lab 1 is set in Print format, select line number and press [Print/M+] to save. Setup is then
completed. Line number is the number of transactions sent after which the header will be repeated.
Note I: - If Lab 2 is set in Print format, select also the number of copies and press [Print/M+] to save. Setup
is then completed.
Note J: - If Lab 3, 4 or 5 is set in Print format, press [Print/M+] to save. Setup is then completed.
Note K: - If LP50/TSC/Sbarco is selected: -
a. Select number of copy (1 ~ 8) and press [Print/M+] to continue the below setting,
b. Select label file number (FL1 00 ~ FL1 99) to print in label format group 1 and press [Print/M+]
to continue the below setting. FL1 00 = current transaction label printing output disabled.
c. Select label file number (FL2 00 ~ FL2 99) to print in label format group 2 and press [Print/M+]
to continue the below setting. FL2 00 = totalized (MR) data label printing output disabled.
8.4 When Bluetooth, WIFI & LAN is selected
Some other settings are required. Contact your dealer for setting information and assistance.
