Appendix T: - Production Settings PLU Saving Commands
Production Settings PLU saving commands format as below: -
a. Start String * “asterisk” (Hex code 02A), followed by
b. Command code as shown on below table (all commands are case sensitive), followed by
c. Parameters listed on the below table. Always insert semicolon (;) in front of each parameter, followed by
d. End String # “number sign” (Hex code 23).
Notes: -
For RS485 communication, add @xx before start string.
xx = machine ID number set in F18.
T.1 Command Description Table
Note T1: -
• S1 = command for operation with weight unit = kg.
• S2 = command for operation with weight unit = g.
• S3 = command for operation with weight unit = lb.
T.2 Parameter Description Table
