9.10 Select the Preferred Function Mode
8
This instrument supports the below-working modes. The abbreviation of each working mode is bracketed.
 Weighing (Weigh).
 Piece Count (Count).
 Action-Tare-Memory (AtM).
 Animal Weighing (Ani).
 Quick access to Customer & Product Code Setting (PCd).
Press [Func] to enter function selection mode and press [Unit] until the abbreviation of the desired working
mode appears and press [Print/M+] to enter.
The working mode employed before powering off will be employed again when powered on.
9.11 Check Functions
9
10
11
12
This instrument is equipped with Lo/Hi check function. Check targets of various working modes are: -
 Weighing mode = weight value.
 Piece Count mode = piece value.
 Auto Tare Accumulation mode = weight value.
9.11.1 Input check limits manually
1. Select preferred weight unit and working mode.
2. Press [Check], then input the Lo limit value.
3. Press [Print/M+], then input the Hi limit value.
4. Press [Print/M+]. The Lo and Hi limits are now in effect.
9.11.2 Cancel check limits inputted
Refer to paragraph 9.11.1 and press [CE/x10] when prompted for value in step 2 and 3.
9.11.3 Hints for entering Lo & Hi Limits
1. For typical comparison, set both Lo and Hi limits.
2. To check if the result is lower than or equal to Lo (result ≤ LO), set Hi limit = 0.
3. To check if the result is higher than or equal to Hi (result ≥ HI), set Lo limit = 0.
4. To check if the result is equal to a specified value, set both Hi limit and Lo limit = the specified value.
9.12 Tri-color Backlight
This instrument is equipped with a tri-color backlight. The 3 colors are yellow, green and red.
• In typical operation, green is used for display illumination.
• When check function is activated: - yellow = Lo; green = OK; red = Hi.
8
Depends on F11 setting. Weighing mode cannot be disabled.
9
Check function does not support Animal Weighing mode.
10
Check mode will not operate when weight is less than 20d (or 20d
1
for dual weighing range/interval mode).
11
Set also F15 for desired Check buzzer output.
12
Refer to F25 of paragraph 6.4 for static, standard and dynamic check mode settings.
