Appendix Q: - Operation Result Reading Commands
Operation result reading command format as below: -
a. Start String * “asterisk” (Hex code 02A), followed by
b. Command code as shown on below table (all commands are case sensitive), followed by
c. End String # “number sign” (Hex code 23).
Notes: -
 For RS485 communication, add @xx before start string.
 xx = machine ID number set in F18.
Command Description Table
Command Definition
Command Format
Parameter
Output
Parameter Description
Start String
Command
Code
End String
Read Average piece weight
*
RD
AVGW
#
d1
8 digits including decimal (if any)
Read Current Tare Weight
*
RD
CWTA
#
d1
8 digits including decimal
Read Current Gross Weight
*
RD
CWGS
#
d1
8 digits including decimal (if any)
Read Current Net Weight
*
RD
CWNT
#
d1
8 digits including decimal (if any)
Read Weight Unit of Current Net, Tare and
Gross Weight
*
RD
CWUN
#
d1
8 digits including decimal (if any)
Read Qty Value
*
RD
CQTY
#
d1
8 digits
Read Low Limit
*
RD
CHKL
#
d1
8 digits including decimal (if any)
Read High Limit
*
RD
CHKH
#
d1
8 digits including decimal (if any)
Read Check Target
*
RD
CHKT
#
d1
kg = kilogram, (space)g = gram,
pcs = quantity
Read Check Result
*
RD
CHKR
#
d1
Below/Accept/Above
Read Accumulated Gross Weight
*
RD
AWGS
#
d1
8 digits including decimal (if any)
