7. Recommended Setting Procedures for User
1. Power off this instrument and remove the power adaptor.
2. Complete all hardware connections with peripherals.
3. Apply power adaptor and power on instrument.
4. Go to F1 and check the internal count value. Internal count value should increase when extra loads
are applied. Likewise, the internal count value decreases when loads are removed.
5. Go to F2 and check and make sure no display segments or indicators are missing.
6. Go to F3 and make sure that capacity x division is correctly set.
7. Go to F4 to check and set date format and value.
8. Go to F5 to check and set the time value.
9. Go to F6 to do system initialization.
10. Check and set all other operation parameters from F7, F8, F9…. F37 according to the numeric
sequence of the internal function number.
11. Conduct test runs to determine if the above settings are the best suit the application requirements. If
not, set the corresponding parameters again.
12. If Alibi memory will be used, contact your dealer for support.
Always contact your dealer for product information, after-sales service, and questions when in doubt.
8. UART & Comport Settings
This instrument is with 5 built-in UARTs (UART 0 ~ 4 and LAN). Refer to the below table for transmission type
and assigned comport number.
8.1 UART Transmission Type & Assigned Comport No. Table
Note: - only one transmission type can be selected per each of UART 0 ~ 4 and LAN.
Setting procedures: -
1. Go to F16 and press [Print/M+].
2. Name of the current UART # appears.
3. Press [Unit] until the preferred UART # (UART 0 ~ 4 or LAN) appears and press [Print/M+].
4. Press [Unit] or [MR] until the preferred transmission type appears and press [Print/M+] to set data
communication types. Depends on transmission type, maximum 8 parameters are available: -
• Off = Disabled.
• Auto 1 = Auto print when weight is stable.
