Appendix O: - System Parameter & Operation Entry Setting Commands
System parameter & operation entry setting command format as below: -
a. Start String * “asterisk” (Hex code 02A), followed by
b. Command code as shown on below table (all commands are case sensitive), followed by
c. Parameter(s) listed on the below table. Always insert semicolon (;) in front of each parameter, followed by
d. End String # “number sign” (Hex code 23).
Notes: -
 For RS485 communication, add @xx before start string.
 xx = machine ID number set in F18.
Command Description Table
Command Definition
Command Format
Parameter Description
Start
String
Command Code
Parameter
&
End String
Set Date Format, Value and Output
*
ST
F004
;d1;d2;d3#
 d1 = Date Format (0 = DD-MM-YY, 1 = YY-MM-DD,
2 = MM-DD-YY)
 d2 = 8-digit date value as per above setting (AA-
BB-CC)
 d3 = Date Output Format (0 = Normal Format, 1 =
Week Format)
Set Time
*
ST
F005
;d1#
8-digit time value (HH:MM:SS)
Set Auto Power Off
*
ST
F007
;d1#
0 = Off, 1 = 1 minute, 2 = 3 minute, 3 = 5 minute
4 = 10 minute, 5 = 20 minute, HH:MM:SS = exact power
off time
Set Brightness and Color Ratio
*
ST
F008
;d1;d2#
 d1 = Brightness (01~99)
 d2 =Color Ratio (01~99)
Set Filter Strength & AD Conversion
Speed
*
ST
F010
;d1;d2#
 d1= Filter (1~9 for Filter 1~9)
 d2 = AD Conversion Speed (015/030/060/120)
Set Auto Tare Function
*
ST
F012
;d1#
M = Off, A = Auto, 00 ~ 99 = Continuous tare (in term of
