FISCHER Mess- und Regeltechnik GmbH Operation | 5
BA_EN_FT90 57/108
5.5.1.2.1 Measuring range C1 unit
Differential pressure
Path: \Configuration\Channel 1\Measurement C1\Meas.range C1 unit
Level: 4
Meas.range C1 unit
1 2 3 4
bar
mbar
Pa
kPa
R
S
U
R
R
Fig.77: Measuring range C1 unit
Implemented pressure units:
Unit Description
bar bar Metric and SI units
mbar milli bar
Pa Pascal
kPa kilo Pascal
MPa Mega Pascal
psi pound-force per square inch Anglo-American units (Imperial
Units)
inH₂O inch water column
mmH₂O mm Water column Historical units
mmHg mm Mercury column
If the pressure unit changes, all parameters are automatically converted.
Temperature
Path: \Configuration\Channel 1\Measurement C1\Meas.range C1 unit
Level: 4
Meas.range C1 unit
1 2 3 4
°C
°F
Back
S
E
U
R
Fig.78: Measuring range C1 unit
Implemented temperature units:
Unit Description
°C Celsius Metric and SI units
°F Fahrenheit Anglo-American units (imperial
units)
Humidity
The unit for humidity is fixed as %rH .
