FLEX-6000 Signature Series – Maestro User Guide
Copyright 2024 FlexRadio, Inc. All Rights Reserved. | Page 156
RCA TX Req: Enables the RCA TX Request line when selected. When active, the RCA TX Req line
must be in the appropriate state (depending on the polarity set on the Settings -> TX Tab) to allow
for transmission.
ACC TX Req: Enabled the ACC TX Request line when selected. When active, the ACC TX Req line
must be in the appropriate state (depending on the polarity set on the Settings -> TX Tab) to allow
for transmission.
RCA TX1/2/3: When selected, the TX1/2/3 RCA output is pulled to ground during transmission.
HWALC: Enables the RCA Hardware ALC circuit when selected.
Note: For the timing settings for several of these controls which apply to all bands, see the
Transmit Tab, section 33.7.
