Flowserve Limitorque MX-40 - Figure 5.6 - Power Board; Figure 5.7 - DDC Board

103
Limitorque MX Maintenance and Spare Parts FCD LMENIM2314-00 – 07/08
flowserve.com
Figure 5.6 shows the location of the EPROM on the Power Board.
Figure 5.6 – Power Board
NOTE: Power board EPROM is not included in replacement kit. This EPROM should not be replaced in
the field.
Figure 5.7 shows the location of the DDC EPROM on the DDC Option Board.
Figure 5.7 – DDC Board
