Flowserve Limitorque MX-40 - Handwheel Adapter (MX-05); Figure 4.22 - Handwheel Adapter (MX-05); Figure 4.23 - Handwheel (MX-05); Table 4.20 - Handwheel Adapter Parts List (MX-05)

77
Limitorque MX Maintenance and Spare Parts FCD LMENIM2314-00 – 07/08
flowserve.com
4.13 Handwheel Adapter (MX-05)
Table 4.20 – Handwheel Adapter Parts List (MX-05)
Part Number Description Qty.
12-1 Handwheel adapter 1
12-2 Needle bearing 1
12-3 Quad ring 1
12-4 O-ring 1
Figure 4.22 – Handwheel Adapter (MX-05)




Figure 4.23 – Handwheel (MX-05)
.9POMZ)BOEXIFFM4QBDFS
8BWF4QSJOH
