Limitorque MX Maintenance and Spare Parts FCD LMENIM2314-00 – 07/08
82
Table 4.22 – Handwheel Worm Gear Assembly Parts List
Part Number Description Qty.
12-1 Handwheel worm gear 1
12-2 Ball bearing 1
12-3 Quad ring 1
12-4 O-ring 1
12-5 Handwheel adapter 1
Figure 4.25 – Handwheel Worm Gear Assembly




