Limitorque MX Maintenance and Spare Parts FCD LMENIM2314-00 – 07/08
34
STEP 4
Align the handwheel slots with the mounting
holes. Fit the four screws (#1-11) in handwheel
mounting holes and tighten.
4
Swanson Flo | 800-288-7926 | www.swansonflo.com
