Limitorque QX Electronic Actuator FCD LMENIM3306-06 – 07/14
24
a
CAUTION: Do not melt the insulation.
6. Connect the network cables to the QX actuator terminal block per Table 3.3 and appropriate wiring diagram. Table
3.5 details a connection for the loop topology.
Figure 3.9 – Separating cable parts
Figure 3.10 – Stripping conductors and applying heat shrink tubing
Figure 3.11 – Ring tongue connectors
