Figure 4.22 – Change Analog Out
YES YES
NOOUT 2? ON-OK? ATT-OK?
NO
CHANGE
ANALOG OUT?
ANALOG
OUT 1?
YES YES
NO
NO
STATUS
ON-OK?
STATUS FUNCTION
APT-OK?
Figure 4.23 – Change Analog Out Voltage – APT
Figure 4.24 – Change Analog Out Current – APT
YES YES
NO0-10VDC-OK?
0-5VDC-OK?
1-5VDC-OK?
CLOSE-OK?
NO
ANALOG OUT
VOLTAGE-OK?
YES
NO
OFFSET
2-10VDC-OK?
POLARITY 10VDC
OPEN-OK?
YES
NO
CALIBRATE
LOW SIGNAL?
YES
NO
YES
NO
CALIBRATE
HIGH SIGNAL?
SAVE
SETTINGS?
YES
NO
10VDC
OK?
YES
NO
2VDC
OK?
If 5VDC option
selected: “5VDC”
will be displayed.
YES YES
NO0-20MA-OK? CLOSE-OK?
NO
ANALOG OUT
CURRENT-OK?
YES
NO
OFFSET
4-20MA-OK?
POLARITY 20MA
OPEN-OK?
YES
NO
CALIBRATE
LOW SIGNAL?
YES
NO
YES
NO
CALIBRATE
HIGH SIGNAL?
SAVE
SETTINGS?
YES
NO
20MA
OK?
YES
NO
4MA
OK?
