Limitorque QX Electronic Actuator FCD LMENIM3306-06 – 07/14
92
Applicable emissions standards EN61326-1 (CISPR11) Industrial Environments - Class A - Test Limits & Levels
Radiated Emissions
EN55011:2009+A1:2010 (CISPR11)
30 MHz to 230 MHz 40 dB (μV/m)
230 MHz to 1 GHz 47 dB (μV/m)
FCC Part 15, (CFR47 Part 15.109)
30 MHz to 88 MHz 90 dB (μV/m)
88 MHz to 216 MHz 150 dB (μV/m)
216 MHz to 960 MHz 210 dB (μV/m)
> 960 MHz 300 dB (μV/m)
Conducted Emissions
EN55011:2009+A1:2010 (CISPR11) 150 kHz to 500 kHz 79 dB (μV) (quasi-pk), 66 dB (μV) (avg)
FCC Part 15, (CFR47 Part 15.107) 500 kHz to 30 MHz 73 dB (μV) (quasi-pk), 60 dB (μV) (avg)
Applicable immunity standards EN61000-6-2:2005 (Perf. Criteron) Industrial Environments - Test Limits & Levels
ESD IEC61000-4-2 (B)
Contact ±1 kV, ±2 kV, ±4 kV
Air ±2 kV, ±4 kV, ±6kV, ±8 kV
Radiated RF immunity IEC61000-4-3 (A)
Enclosure @ 80 MHz to 1 GHz 10 Vrms/m @ 80% AM, 1 kHz
Enclosure @ 1 GHz to 2.7 GHz 3 Vrms/m @ 80% AM, 1 kHz
Enclosure @ 2 GHz to 2.7 GHz 1 Vrms/m @ 80% AM, 1 kHz
Fast transients/burst IEC61000-4-4 (B)
AC Power, DC Power ±2 kV
I/O (mains connected) ±2 kV
I/O (non-mains) ±1 kV
Voltage surges IEC61000-4-5 (B)
AC Power, DC Power ±1 kV (DM), ±2 kV (CM)
I/O (mains connected) ±2 kV (CM)
I/O (non-mains) ±1 kV (CM)
Conducted RF immunity EN61000-4-6 (A)
AC Power, DC Power, I/O
@ 150 kHz to 80 MHz
3 Vrms @ 80% AM, 1 kHz
Magnetic field immunity EN61000-4-8 (A) Three mounting axis, X, Y, Z 30 A/m, 60 sec dwell
Voltage dips and interrupts
IEC61000-4-11 (B)
3 dips, 10 sec apart 100% dip for 1 cycle @ 50/60 Hz
3 dips, 10 sec apart 60% dip for 200 ms @ 50/60 Hz
3 dips, 10 sec apart 30% dip for 500 ms @ 50/60 Hz
EN61000-4-11 (C) 3 dips, 10 sec apart 100% interrupt for 5 sec @ 50/60 Hz
