Fluke 6270A - Page 111

Pressure Controller/Calibrator
Calibration Tables
105
Table 38. PM600- A350K Pressure Point Matrix
As Found / As Left Points
Calibration Segment Pressure No.
Set Pressure
[kPa]
Dwell Time [s]
Averaging Time
[s]
Ascending Points
1 10 60 30
2 87.5 60 30
3 175 60 30
4 262.5 60 30
5 350 60 30
Descending Points
6 262.5 60 30
7 175 60 30
8 87.5 60 30
9 10 60 30
Table 39. PM600- A700K Pressure Point Matrix
As Found / As Left Points
Calibration Segment Pressure No.
Set Pressure
[kPa]
Dwell Time [s]
Averaging Time
[s]
Ascending Points
1 20 60 30
2 175 60 30
3 350 60 30
4 525 60 30
5 700 60 30
Descending Points
6 525 60 30
7 350 60 30
8 175 60 30
9 20 60 30
