Table 40. PM600- A1.4M Pressure Point Matrix
As Found / As Left Points
Calibration Segment Pressure No.
Set Pressure
[kPa]
Dwell Time [s]
Averaging
Time [s]
Ascending Points
1 35 60 30
2 350 60 30
3 700 60 30
4 1050 60 30
5 1400 60 30
Descending Points
6 1050 60 30
7 700 60 30
8 350 60 30
9 35 60 30
Table 41. PM600- A2M Pressure Point Matrix
As Found / As Left Points
Calibration Segment Pressure No.
Set Pressure
[kPa]
Dwell Time [s]
Averaging
Time [s]
Ascending Points
1 70 60 30
2 500 60 30
3 1000 60 30
4 1500 60 30
5 2000 60 30
Descending Points
6 1500 60 30
7 1000 60 30
8 500 60 30
9 70 60 30
