Fluke 6270A - Page 113

Pressure Controller/Calibrator
Calibration Tables
107
Table 42. PM600- A3.5M Pressure Point Matrix
As Found / As Left Points
Calibration Segment Pressure No.
Set Pressure
[kPa]
Dwell Time [s]
Averaging Time
[s]
Ascending Points
1 70 60 30
2 875 60 30
3 1750 60 30
4 2625 60 30
5 3500 60 30
Descending Points
6 2625 60 30
7 1750 60 30
8 875 60 30
9 70 60 30
Table 43. PM600- A7M Pressure Point Matrix
As Found / As Left Points
Calibration Segment Pressure No.
Set Pressure
[kPa]
Dwell Time [s]
Averaging Time
[s]
Ascending Points
1 ATM
1
60 30
2 1750 60 30
3 3500 60 30
4 5250 60 30
5 7000 60 30
Descending Points
6 5250 60 30
7 3500 60 30
8 1750 60 30
9 ATM
1
60 30
1. ATM: atmospheric pressure from laboratory barometer via PG system.
