Fluke 6270A - Page 114

6270A
Service Manual
108
Table 44. PM600- A10M Pressure Point Matrix
As Found / As Left Points
Calibration Segment Pressure No.
Set Pressure
[kPa]
Dwell Time [s]
Averaging Time
[s]
Ascending Points
1 ATM
1
60 30
2 2500 60 30
3 5000 60 30
4 7500 60 30
5 10000 60 30
Descending Points
6 7500 60 30
7 5000 60 30
8 2500 60 30
9 ATM
1
60 30
1. ATM: atmospheric pressure from laboratory barometer via PG system.
Table 45. PM600- A14M Pressure Point Matrix
As Found / As Left Points
Calibration Segment Pressure No.
Set Pressure
[kPa]
Dwell Time [s]
Averaging
Time [s]
Ascending Points
1 ATM
1
60 30
2 3500 60 30
3 7000 60 30
4 10500 60 30
5 14000 60 30
Descending Points
6 10500 60 30
7 7000 60 30
8 3500 60 30
9 ATM
1
60 30
1. ATM: atmospheric pressure from laboratory barometer via PG system.
