810
Users Manual
3-14
Table 3-4. Tester Settings
Option Description
Power line freq
Set the ac power line frequency to 60Hz or 50Hz. The diagnostic quality of a test depends on the
correct selection of the ac power line frequency.
Date format Set the Date format as d/m/y or m/d/y
Date Scroll and set the Day, Month, and Year fields
Time format Set the Time format as 12Hr or 24Hr
Time Scroll and set the Hour, Minute, and AM or PM fields
Beeper Set the Beeper as ON or OFF
Backlight brightness Set the display brightness as High or Low
Power save
Scroll and select to set the delay time for the Sleep Mode. If no key is pushed during the set time, the
Tester goes into the sleep mode to save battery power. Any key push cancels the sleep mode and
resumes normal operation.
Backlight duration
Scroll and select to set the delay time for the display backlight. If no key is pushed during the set
time, the backlight turns off to save battery power. The backlight turns on when any key is pushed.
Time waveform
capture
Scroll and select the number of measurements where the time waveform is to be captured. The
Tester captures and stores the time waveform data for the selected number of measurements.
Note
Capture and review of time waveform data is useful in advanced vibration analysis, but keep in mind
that data capture uses a significant amount of memory. Captured time waveforms can only be
viewed in the Viewer Software, not the Tester.
Units
Scroll and select a unit of measurement as US or metric. Also select the units for the vibration
amplitude. VdB and in/sec for US. VdB* indicates VdB Europe and mm/sec for Metric.
Language Scroll and select a language.
