810
Users Manual
4-32
9. Push Enter to select the location. The Tester
display shows that the Sensor is located.
Table 4-16 is a list of the softkey functions for the Sensor
Placement screen.
Table 4-16. Sensor Placement Functions
Softkey Function
Change Go back to the previous screen to
change the Sensor location.
Measure
Tips
Display information and tips for taking
measurements.
Enter Displays the Sensor Orientation screen.
Exit Exit to the Startup screen.
