FOR-A MFR Series User Manual

100
 SNMP Trap
Object name in MIB file
Trap condition
1
3
5
8
A
O
mfrTrap
mfrMuPower1AlarmTrap
Power Supply unit 1 internal voltage is abnormal or recovered.
Y
Y
Y
Y
Y
Y
mfrMuPower2AlarmTrap
Power Supply unit 2 internal voltage is abnormal or recovered.
Y
Y
Y
Y
Y
Y
mfrMuFan1AlarmTrap
Main unit cooling fan 1 is abnormal or recovered.
Y
Y
Y
Y
N
Y
mfrMuFan2AlarmTrap
Main unit cooling fan 2 is abnormal or recovered.
Y
Y
Y
Y
N
N
mfrMuFan3AlarmTrap
Main unit cooling fan 3 is abnormal or recovered.
Y
Y
Y
Y
N
N
mfrMuFan4AlarmTrap
Main unit cooling fan 4 is abnormal or recovered.
Y
Y
Y
Y
N
N
mfrMuFan5AlarmTrap
Main unit cooling fan 5 is abnormal or recovered.
N
N
N
Y
N
N
mfrMuFan6AlarmTrap
Main unit cooling fan 6 is abnormal or recovered.
N
N
N
Y
N
N
mfrMuFan7AlarmTrap
Main unit cooling fan 7 is abnormal or recovered.
N
N
N
Y
N
N
mfrMuFan8AlarmTrap
Main unit cooling fan 8 is abnormal or recovered.
N
N
N
Y
N
N
mfrMuActiveCpuTrap
CPU2 is activated.
N
Y
Y
Y
Y
Y
mfrMuCpu1VoltAlarmTrap
CPU1 board internal voltage is abnormal or recovered.
Y
Y
Y
Y
Y
Y
mfrMuCpu2VoltAlarmTrap
CPU2 board internal voltage is abnormal or recovered.
N
Y
Y
Y
N
Y
mfr5kMtxVoltAlarmTrap
Matrix board cooling fan is abnormal or recovered.
N
N
Y
Y
N
N
mfr5kMtxXptErrorTrap
Crosspoint errors happen on the Matrix board.
N
Y
Y
Y
N
N
mfr8kMtxFanAlarmTrap
Matrix board is abnormal or recovered.
N
N
N
Y
N
N
mfr5kRear1VoltAlarmTrap
Rear card 1 voltage is abnormal or recovered.
N
N
Y
Y
N
N
mfr5kRear2VoltAlarmTrap
Rear card 2 voltage is abnormal or recovered
N
N
Y
Y
N
N
mfr5kSlotStatusAlarmTrap
Input / Output boards are abnormal or recovered.
N
N
Y
Y
N
N
mfrMuChangeMasterTrap
Master unit ID is changed.
Y
Y
Y
Y
Y
Y
mfrRuPower1AlarmTrap
Remote control unit Power Supply unit1 is abnormal or
recovered.
Y
Y
Y
Y
Y
Y
mfrRuPower2AlarmTrap
Remote control unit Power Supply unit2 is abnormal or
recovered.
Y
Y
Y
Y
Y
Y
mfrRuVoltAlarmTrap
Remote control unit internal voltage is abnormal or recovered.
Y
Y
Y
Y
Y
Y
mfrGpiPower1AlarmTrap
MFR-GPI or MFR-TALM Power Supply unit 1 is abnormal or
recovered.
Y
Y
Y
Y
Y
Y
mfrGpiPower2AlarmTrap
MFR-GPI or MFR-TALM Power Supply unit 2 is abnormal or
recovered.
Y
Y
Y
Y
Y
Y
mfrGpiVoltAlarmTrap
MFR-GPI or MFR-TALM internal voltage is abnormal or
recovered.
Y
Y
Y
Y
Y
Y
mfrLanLinkTrap
An MFR Series device is disconnected or connected.
Y
Y
Y
Y
Y
Y
When CPUs are in Passive state, only CPU monitoring of “mfrMuCpuStatus > mfrMuActiveCpu, mfrMuMaster,
mfrMuMasterID” can be performed.
 MFR OID list
Object group
Object name in MIB file
OID
Return value
mfrTrap
.1.3.6.1.4.1.20175.1.304.10
mfrMuPower1AlarmTrap
.1.3.6.1.4.1.20175.1.304.10.1
mfrMuPower1Alarm
mfrMuPower2AlarmTrap
.1.3.6.1.4.1.20175.1.304.10.2
mfrMuPower2Alarm
mfrMuFan1AlarmTrap
.1.3.6.1.4.1.20175.1.304.10.3
mfrMuFan1Alarm
mfrMuFan2AlarmTrap
.1.3.6.1.4.1.20175.1.304.10.4
mfrMuFan2Alarm
mfrMuFan3AlarmTrap
.1.3.6.1.4.1.20175.1.304.10.5
mfrMuFan3Alarm
mfrMuFan4AlarmTrap
.1.3.6.1.4.1.20175.1.304.10.6
mfrMuFan4Alarm
mfrMuActiveCpuTrap
.1.3.6.1.4.1.20175.1.304.10.7
mfrMuActiveCpu
mfrMuCpu1VoltAlarmTrap
.1.3.6.1.4.1.20175.1.304.10.8
mfrMuCpu1VoltAlarm
mfrMuCpu2VoltAlarmTrap
.1.3.6.1.4.1.20175.1.304.10.9
mfrMuCpu2VoltAlarm
mfr5kMtxVoltAlarmTrap
.1.3.6.1.4.1.20175.1.304.10.10
mfr5kMtxVoltAlarm
mfr5kMtxXptErrorTrap
.1.3.6.1.4.1.20175.1.304.10.11
mfr5kMtxXptError
mfr5kRear1VoltAlarmTrap
.1.3.6.1.4.1.20175.1.304.10.12
mfr5kRear1VoltAlarm
mfr5kRear2VoltAlarmTrap
.1.3.6.1.4.1.20175.1.304.10.13
mfr5kRear2VoltAlarm
mfr5kSlotStatusAlarmTrap
.1.3.6.1.4.1.20175.1.304.10.14
mfr5kSlotStatus
mfrRuPower1AlarmTrap
.1.3.6.1.4.1.20175.1.304.10.15
mfrRuPower1Alarm
mfrRuPower2AlarmTrap
.1.3.6.1.4.1.20175.1.304.10.16
mfrRuPower2Alarm
mfrRuVoltAlarmTrap
.1.3.6.1.4.1.20175.1.304.10.17
mfrRuVoltAlarm
mfrGpiPower1AlarmTrap
.1.3.6.1.4.1.20175.1.304.10.18
mfrGpiPower1Alarm
mfrGpiPower2AlarmTrap
.1.3.6.1.4.1.20175.1.304.10.19
mfrGpiPower2Alarm
mfrGpiVoltAlarmTrap
.1.3.6.1.4.1.20175.1.304.10.20
mfrGpiVoltAlarm
mfrLanLinkTrap
.1.3.6.1.4.1.20175.1.304.10.21
mfrRuID, mfrRuLinkStatus
mfrMuFan5AlarmTrap
.1.3.6.1.4.1.20175.1.304.10.22
mfrMuFan5Alarm
mfrMuFan6AlarmTrap
.1.3.6.1.4.1.20175.1.304.10.23
mfrMuFan6Alarm
mfrMuFan7AlarmTrap
.1.3.6.1.4.1.20175.1.304.10.24
mfrMuFan7Alarm
mfrMuFan8AlarmTrap
.1.3.6.1.4.1.20175.1.304.10.25
mfrMuFan8Alarm
mfr8kMtxFanAlarmTrap
.1.3.6.1.4.1.20175.1.304.10.26
mfr8kMtxFanAlarm
mfrMuChangeMasterTrap
.1.3.6.1.4.1.20175.1.304.10.27
mfrMuMasterID
1: MFR-1000 A: MFR-1616A
3: MFR-3000 O: Other MFR MUs
5: MFR-5000 Y: Supported, N: Unsupported
8: MFR-8000
