91
TCP/IP
Parameter
Default
Description
Access Method
Free
Allows you to select access mode.
Free: Controllable from any control PC.
Client: Controllable only from the PC selected
under Client Settings.
Default Function
Unused
Server (MFR) (MFR-TALM)
TCP Port
Unused
UDP Port
23
Allows you to set the Server UDP port number.
KeepAlive
Unused
Client Settings
Client Settings
1
Assigns the client (PC) identification number.
(Setting range: 1 to 16)
IP Address
0.0.0.0
Enters the PC IP address.
Setting the IP address enables the communication.
Port
Any
Allows you to set the PC TC/UDP port number.
Check Any when not setting a port number.
To enable the connection from a specific port,
uncheck Any, then enter the port number in the
right setting box.
If the port number remains unspecified, the PC is
connected via any available port at the start of
every communication protocol.
Unit ID
Server ID
Unused
Protocol
UDP
Fixed to UDP.
Function
None
Selects the communication protocol.
* The following parameters are displayed when TSL UMD protocol V5.0 Tally out is
selected.
Encode
ASCII
Selects the character code from ASCII, Unicode
(Kanji), or Unicode (Import).
DLE
ON
Selects ON or OFF for Data Link Escape.
Screen No.
0
Selects the TSL screen number.
ID Range
MV-1 to MV-256
Sets the TSL output range. (See Sec. 4-2-4.
"DP-MV Tally.")
Server ID
60 (192.168.1.62)
Sets the MFR-TALM Unit ID.
* The server IP Address is displayed in
parentheses.
Disable
---
Allows you to Enable/disable the current "Client
Settings."
Session
Information
A list of active sessions
Check Delete, and click Send to terminate the
session.
NOTE
The number of concurrent server sessions allowed is 16.
Click the Send button to save the settings after they are changed.
