REGISTER SUMMARY MC68332
D-4 USER’S MANUAL
Table D-2 SIM Address Map
Access Address 15 8 7 0
S $YFFA00 SIM CONFIGURATION (SIMCR)
S $YFFA02 FACTORY TEST (SIMTR)
S $YFFA04 CLOCK SYNTHESIZER CONTROL (SYNCR)
S $YFFA06 NOT USED RESET STATUS REGISTER (RSR)
S $YFFA08 MODULE TEST E (SIMTRE)
S $YFFA0A NOT USED NOT USED
S $YFFA0C NOT USED NOT USED
S $YFFA0E NOT USED NOT USED
S/U $YFFA10 NOT USED PORT E DATA (PORTE0)
S/U $YFFA12 NOT USED PORT E DATA (PORTE1)
S/U $YFFA14 NOT USED PORT E DATA DIRECTION (DDRE)
S $YFFA16 NOT USED PORT E PIN ASSIGNMENT (PEPAR)
S/U $YFFA18 NOT USED PORT F DATA (PORTF0)
S/U $YFFA1A NOT USED PORT F DATA (PORTF1)
S/U $YFFA1C NOT USED PORT F DATA DIRECTION (DDRF)
S $YFFA1E NOT USED PORT F PIN ASSIGNMENT (PFPAR)
S $YFFA20 NOT USED SYSTEM PROTECTION CONTROL
(SYPCR)
S $YFFA22 PERIODIC INTERRUPT CONTROL (PICR)
S $YFFA24 PERIODIC INTERRUPT TIMING (PITR)
S $YFFA26 NOT USED SOFTWARE SERVICE (SWSR)
S $YFFA28 NOT USED NOT USED
S $YFFA2A NOT USED NOT USED
S $YFFA2C NOT USED NOT USED
S $YFFA2E NOT USED NOT USED
S $YFFA30 TEST MODULE MASTER SHIFT A (TSTMSRA)
S $YFFA32 TEST MODULE MASTER SHIFT B (TSTMSRB)
S $YFFA34 TEST MODULE SHIFT COUNT (TSTSC)
S $YFFA36 TEST MODULE REPETITION COUNTER (TSTRC)
S $YFFA38 TEST MODULE CONTROL (CREG)
S/U $YFFA3A TEST MODULE DISTRIBUTED REGISTER (DREG)
$YFFA3C NOT USED NOT USED
$YFFA3E NOT USED NOT USED
S/U $YFFA40 NOT USED PORT C DATA (PORTC)
$YFFA42 NOT USED NOT USED
S $YFFA44 CHIP-SELECT PIN ASSIGNMENT (CSPAR0)
S $YFFA46 CHIP-SELECT PIN ASSIGNMENT (CSPAR1)
S $YFFA48 CHIP-SELECT BASE BOOT (CSBARBT)
S $YFFA4A CHIP-SELECT OPTION BOOT (CSORBT)
S $YFFA4C CHIP-SELECT BASE 0 (CSBAR0)
S $YFFA4E CHIP-SELECT OPTION 0 (CSOR0)
S $YFFA50 CHIP-SELECT BASE 1 (CSBAR1)
S $YFFA52 CHIP-SELECT OPTION 1 (CSOR1)
S $YFFA54 CHIP-SELECT BASE 2 (CSBAR2)
S $YFFA56 CHIP-SELECT OPTION 2 (CSOR2)
S $YFFA58 CHIP-SELECT BASE 3 (CSBAR3)
S $YFFA5A CHIP-SELECT OPTION 3 (CSOR3)
$YFFA5C CHIP-SELECT BASE 4 (CSBAR4)
