Fronius Symo GEN24 10.0

Max. processable PV power
Total
PV 1
PV 2
10300 Wp
10300 Wp
6000 Wp
Max. input voltage
at 1000 W/m² / -10 °C in an open cir-
cuit
1000 V
Feed-in start-up input voltage in grid
operation
5)
80 V
Max. input current
PV 1
PV 2
25.0 A
12.5 A
Max. short circuit current of PV mod-
ules (I
SC PV
)
PV 1
PV 2
37.5 A
18.75 A
Max. short circuit current
(I
SC PV1
+ I
SC PV2
= I
SC max
)
Total
56.25 A
Max. inverter backfeed current to the
array
3)
37.5 A
Number of inputs - PV 1 2
Number of inputs - PV 2 1
Max. capacity of the PV generator
against earth
2000 nF
Insulation resistance test limit value
between PV generator and earth (on
delivery)
10)
100 kΩ
Adjustable range of insulation resist-
ance test between PV generator and
earth
9)
10 - 10000 kΩ
Limit value and tripping time of the
sudden residual current monitoring
(on delivery)
30 / 300 mA / ms
60 / 150 mA / ms
90 / 40 mA / ms
Limit value and tripping time of the
continuous residual current monitor-
ing (on delivery)
300 / 300 mA / ms
Adjustable range of continuous resid-
ual current monitoring
9)
30 - 300 mA
Cyclic repetition of the insulation res-
istance test (on delivery)
24h
Adjustable range for the cyclic repeti-
tion of the insulation resistance test
-
DC input data battery
8)
Max. voltage 531 V / 700 V *
* only with suitable disconnection
device between inverter and battery in
the event of a fault
