Fronius Symo GEN24 10.0 User Manual

Min. voltage 160 V
Max. current 22 A
Max. output 10000 W
DC inputs 1
AC input/output data
Rated power (P
nom
) 10000 W
Max. output power 10000 W
Rated apparent power 10000 W
Nominal mains voltage 3 ~ NPE 220 V / 380 V
3 ~ NPE 230 V / 400 V
Min. mains voltage
154 V
1)
Max. mains voltage
280 V
1)
Max. output current 16.4 A
Nominal output current (at 230 V) 14.5 A
Current (inrush)
6)
9.9 A / 4 ms
Nominal frequency
50 / 60 Hz
1)
Nominal frequency for Full Backup
53 / 63 Hz
1)
Total harmonic distortion < 3.5%
Power factor cos phi
2)
0-1 (adjustable)
0.7-1 (recommended)
Max. permitted mains impedance Z
max
at PCC
4)
None
Maximum output fault current / dura-
tion
80.7 A / 10 ms
AC output data PV Point
Max. output power 4133 W (for 5 s)
Rated power 3000 W
Nominal output current 13 A
Nominal mains voltage 1 ~ NPE 220 V / 230 V / 240 V
Nominal frequency
53 / 63 Hz
1)
Switchover time < 90 s
Power factor cos phi
2)
0 - 1
AC output data Full Backup
8)
Max. output power 12400 W (for 5 s)
Max. output power (per phase) 4133 W (for 5 s)
Rated power 10000 W
Rated power (per phase)
7)
3680 W
Nominal output current (per phase) 16 A
168

Fronius Symo GEN24 10.0 Specifications

General

Model	Fronius Symo GEN24 10.0
Category	Inverter
AC nominal output	10.0 kW
AC grid frequency	50 Hz / 60 Hz
THD	< 3 %
Number of MPP trackers	2
Protection class	IP66
AC Nominal Voltage	230 V / 400 V
Operating Temperature Range	-25°C to +60°C
Max. apparent AC power	10, 000 VA
AC nominal voltage range	230 V
DC connection	4x DC+ and 4x DC- screw terminals
Maximum AC Power	10000 VA
Maximum DC Power	15 kW
AC Voltage Range	180 - 280 V
Cooling	Active cooling
Warranty	5 years
