Fronius Symo GEN24 10.0 User Manual

Nominal mains voltage 3 ~ NPE 220 V / 380 V
3 ~ NPE 230 V / 400 V
Nominal frequency for Full Backup
53 / 63 Hz
1)
Switchover time < 90 s
Power factor cos phi
2)
0 - 1
General data
Maximum efficiency 98.2%
European efficiency (U
mpp nom
) 97.9%
European efficiency (U
mpp max
) 97.7%
European efficiency (U
mpp min
) 97.1%
Self-consumption at night ≤ 10 W
Cooling Controlled forced-air ventilation
Protection class IP 66
Dimensions H x W x D 595 × 529 × 180 mm
Weight 24 kg
Inverter topology Non-insulated transformerless
Permitted ambient temperature -25 °C - +60 °C
Permissible humidity 0–100% (incl. condensation)
EMC emission class B
DC/AC overvoltage category
(in accordance with IEC 62109-1)
2 / 3
Pollution degree 2
Sound pressure 47 dB(A)
Safety class (according to IEC62103) 1
Protection devices
DC isolation measurement Warning / shutdown at R
ISO
< 100
kOHM
Overload performance Operating point shift, power limiter
DC disconnector Integrated
RCMU Integrated
Active anti-islanding method Frequency conversion method
Data communication
WLAN SMA-RP connection
(FCC ID: QKWPILOT01 / IC ID:
12270A-PILOT01)
802.11b/g/n (WPA, WPA2)
Ethernet (LAN) RJ 45, 10/100 MBit
Wired shutdown (WSD) max. 28 devices/WSD chain
max. distance between two devices =
100 m
Modbus RTU SunSpec (2x) RS485 2-wire
169
EN

Fronius Symo GEN24 10.0 Specifications

General

Model	Fronius Symo GEN24 10.0
Category	Inverter
AC nominal output	10.0 kW
AC grid frequency	50 Hz / 60 Hz
THD	< 3 %
Number of MPP trackers	2
Protection class	IP66
AC Nominal Voltage	230 V / 400 V
Operating Temperature Range	-25°C to +60°C
Max. apparent AC power	10, 000 VA
AC nominal voltage range	230 V
DC connection	4x DC+ and 4x DC- screw terminals
Maximum AC Power	10000 VA
Maximum DC Power	15 kW
AC Voltage Range	180 - 280 V
Cooling	Active cooling
Warranty	5 years
