Fronius VR 5000 - MIG;MAG Standard Synergic Welding; General

38
MIG/MAG stan-
dard synergic
welding
The MIG/MAG standard synergic welding process is only available in combination with
the Synergic control panel.
MIG/MAG standard synergic welding
General
On Synergic B control panel:
1. Press the „Material“ button to select the filler metal used.
The assignment of SP depends on the welding database used for the power source.
2. Press the „Wire diameter“ button to select the diameter of the wire electrode used.
The assignment of SP depends on the welding database used for the power source.
3. Use the „Protective gas shield“ button to select the protective gas shield used.
The assignment of SP depends on the welding database used for the power source.
On Synergic A control panel:
4. Press the „Process“ button to select the desired welding process:
MIG/MAG standard synergic welding
5. Press the „Mode“ button to select the desired MIG/MAG mode:
2-step mode
4-step mode
Special 4-step mode
Important! Parameters that have been set on a system component control panel
(e.g. remote control unit) might not be able to be changed on the wirefeeder control
panel.
6. Press the „Parameter selection“ buttons to select the welding parameters to be used
to specify the welding power:
Sheet thickness
Welding current
Wirefeed speed
Welding voltage
