Wasted spark coils connections
Coil
Type
Cars where usually
found
Pin connection
Bosch
F000ZS0103
No integrated
igniter (two spark
plug outputs)
Fiat Palio, Siena, Uno 1.0, 1.5,
1.6, Tempra 2.0
Pin 1: Ignition power (from SparkPRO or similar)
Pin 2: Switched 12V from relay
Bosch 4 cylinders
(3 wires)
F 000 ZS0 213
F 000 ZS0 222
0 221 503 011
No integrated
igniter
Celta, Corsa, Gol Flex, Meriva,
Montana
Vectra 16V
Fiat Linea 1.9 16V
Pin 1a (A): Ignition power (from SparkPRO or similar)
Pin 15 (B): Switched 12V from relay
Pin 1b (C): Ignition power (from SparkPRO or similar)
Bosch 4 cylinders
(3 wires)
F 000 ZS0 203
F 000 ZS0 205
No integrated
igniter
Astra, Kadett, Ipanema, Vectra
8V, Zafira
Pin 1: Ignition power (from SparkPRO or similar)
Pin 2: Switched 12V from relay
Pin 3: Ignition power (from SparkPRO or similar)
47905104
19005212
1208307
(6 wires 4
channels)
No integrated
igniter
Individual cylinder
triggering
Fiat Stilo 1.8 16V
GM Meriva 1.8 16V
GM Zafira 1.8 e 2.0 16V
Pin A cyl. 3: Ignition power (from SparkPRO or similar)
Pin B cyl. 2: Ignition power (from SparkPRO or similar)
Pin C cyl. 1: Ignition power (from SparkPRO or similar)
Pin D cyl. 4: Ignition power (from SparkPRO or similar)
Pin E: Power ground (engine head)
Pin F: Switched 12V from relay
Bosch 6 cylinders
0 221 503 008
No integrated
igniter
GM Omega 4.1, Ford V6
Pin 1: Ignition power (from SparkPRO or similar)
Pin 2: Ignition power (from SparkPRO or similar)
Pin 3: Ignition power (from SparkPRO or similar)
Pin 4: Switched 12V from relay
Delphi 4 cylinders
(round)
Integrated igniter
GM Corsa MPFI (from 98 to
2002)
Pin A: Gray #2 (cylinders 2 and 3)
Pin B: Gray #1 (cylinders 1 and 4)
Pin C: Power ground (engine head)
Pin D: Switched 12V from relay
Delphi 4 cylinders
(square)
Integrated igniter
GM Corsa MPFI (until 97)
Pin 1: Switched 12V from relay
Pin 2: Power ground (engine head)
Pin 3: Gray #1 (cylinders 1 and 4)
Pin 4: Gray #2 (cylinders 2 and 3)
Sagem
96358648
Integrated igniter
Peugeot 1.4
Pin 1: Gray #1 (cylinders 1 and 4)
Pin 2: Gray #2 (cylinders 2 and 3)
Pin 3: Power ground (engine head)
Pin 4: Switched 12V from relay
Bosch 4 cylinders
(4 wires)
032 905 106 B/D
F000ZS0210
Integrated igniter
VW Golf, Bora, Audi A3 and
A4, Seat Ibiza and Córdoba
Pin 1: Gray #1 (cylinders 1 and 4)
Pin 2: Switched 12V from relay
Pin 3: Gray #2 (cylinders 2 and 3)
Pin 4: Power ground (engine head)
Eldor 4 cylinders
(6 wires 4
channels)
06A 905 097
06A 905 104
Integrated igniter
Individual cylinder
triggering
Bora, New Beetle, Polo
Pin 1: Power ground (engine head)
Pin 2: Gray - C (cylinder 4)
Pin 3: Gray - B (cylinder 3)
Pin 4: Gray - D (cylinder 2)
Pin 5: Gray - A (cylinder 1)
Pin 6: Switched 12V from relay
VW V6
078 905 104
Integrated igniter
Audi A4 2.8 V6
Audi A6
Passat 2.8 V6
Pin 1: Power ground (engine head)
Pin 2: Gray #1 (cylinders 1 and 4)
Pin 3: Gray #2 (cylinders 2 and 5)
Pin 4: Gray #3 (cylinders 3 and 6)
Pin 5: Switched 12V from relay
