15 Problem Solving
564
Problem Solving
15
4
Return the handle [1d] to its original position.
5
Close the front door of the High Capacity Feeder.
Note • If the front door of the High Capacity Feeder is not completely closed, a message will appear and
the machine will not operate.
Paper Jams in the Transfer Module
Important • Before pulling out the transfer module, check the touch screen to make sure that no paper remains
in the locations other than the transfer module. Paper may be torn if paper remains in these
locations.
1
Make sure that the machine has stopped, and
open the machine front door.
2
Turn the green handle [2] at the center of the
transfer module to the right until it is in the
horizontal position and then pull the transfer
module out to the end.
3
Remove the visible jammed paper.
Note • If paper is torn, check for any torn pieces of
paper in the unit.
To Next Page
