Specifications
599
Appendix
16
HCF B1-S
Dimensions Width 389 x Depth 610 x Height 377 mm
Weight 29 kg
Space Requirement Width 1,574 x Depth 804 mm (main unit + HCF2 (2000 sheets) + Offset
Catch Tray, and when the bypass tray is fully extended)
Paper Size Standard Size:
Maximum: A3, 12.6 x 19.2", 13 x 19"
Minimum: postcards
*1
Non-Standard Size:
100 (Y direction) x 148 (Y direction) mm - 330 (Y direction) x 488 mm (X
direction)
*2
*1 : When the Post Card Kit is used
*2 : When the length (Y direction) of non-standard size paper is 100 to 181 mm the Post Card
Kit must be used.
Paper Weight 64 - 300 gsm
Paper Capacity / Number
of Trays
2,000 sheets x 1 tray
Important • When using 80 gsm paper.
Power Supply 100-120V/200-240V AC ±10%, 2.5A/1.5A for both 50/60 HZ ± 3%
Power Consumption 360 W or less
Dimensions Width 988 x Depth 762 x Height 992 mm
Weight
160 kg
*
* : The bypass tray and the Large Size UI Kit are not included.
Space Requirement Width 2,045 x Depth 804 mm (main unit + HCF B1-S + Offset Catch Tray)
